Buồng thử nhiệt độ và độ ẩm ASLI

Model

DTH-80A

DTH-80B

DTH-80C

Internal Dimensions

WxHxD (mm)

400X500X400

External Dimensions

WxHxD (mm)

1150X1150X1050

Temperature Range

(RT+10°C) ~+150°C

0~+150°C

-20 ~+150°C

Humidity Range

20%~98%R.H.

Indication Resolution/

Distribution

Uniformity of

Temperature

and Humidity

0.1°C; 0.1% R.H / ±2.0°C; ±3.0% R.H.

Control Accuracy

of Temperature

and Humidity

±0.5°C; ±2.5% R.H.

Temperature Rising/

 Falling Velocity

Temperature rising approx.  0.1~3.0°C/min;

temperature falling approx.  0.1~1.5°C/min;

Interior and Exterior Material

Interior material is SUS 304# stainless steel,exterior is stainless steel or  SEE cold-rolled steel with paint coated.

Insulation Material

Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials

Cooling System

Wind cooling

Protection Devices

Fuse-free switch, overloading protection switch  for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection

Optional Accessories

Inner door with operation hole(Optional),

Recorder(optional),Water Purifier

Compressor

French Tecumseh Brand, Germany Bizer Brand

Power

AC 220V(±10%), 1 ph 3  Lines , 50/60HZ;

Weight (Kg)

75
