Máy kiểm tra tốc độ thay đổi nhanh nhiệt độ độ ẩm ASLI

Model

F-TH-80 (A~F)

F-TH-150 (A~ F)

F-TH-225 (A~F)

F-TH-408 (A~F)

F-TH-800 (A~ F)

F-TH-1000 (A~F)

W x H x D(cm)

40x50x40

50 x 60 x 50

60 x 75 x 50

80 x 85 x60

100x100x80

100x100x100

W x H x D(cm)

120x165x115

130x170x125

140x185x130

165x195x155

185x200x175

190x210x185

Temperature range

High temperature:150°C (200°C )

Humidity range

20%~98% R.H. ( 10%~98%R.H ) ; (5%~98%R.H is a special selection condition)

Temperature and humidity analysis
accuracy/distribution accuracy

0.1°C 0.1%R.H./±2.0°C ±3.0%R.H.

Temperature and humidity
control accuracy

±0.5°C, ±2.5%R.H.

heating/cooling time

Temperature Range: -40~+150ºC;
Range of Fast Temperature Change:-45~+85ºC;
Max. temperature rising/falling speed is 20ºC/min when the whole process with linear control .

Internal and external materials

The inner and outer boxes are made of SUS304# stainless steel plate (optional paint)

Insulation material

High temperature resistant high density ethyl chloroformate foam insulation material

Cooling system

Air-cooled/single-stage compressor (-20°C); two-stage compressor (-40°C-70°C)

Safety protection device

No fuse switch, compressor overload protection, refrigerant high and low pressure protection, over-humidity over-temperature
protection, fuse, fault warning system, water shortage alarm protection

Accessories

Operation hole built-in glass door (optional), recorder (optional), viewing window, 50mm test hole,
PL box light, partition, dry and wet ball gauze, casters, leveling stand

Power supply

AC380V 50/60Hz3∮
