Tủ thử nghiệm môi trường sốc nhiệt ở nhiệt độ cao ASLI

Name

Thermal Shock Test Chamber

Model

TS-80(A~C)

TS-150(A~C)

TS-252(A~C)

Internal Dimension WxHxD (mm)

500x400x400

600x500x500

700x600x600

External Dimension WxHxD (mm)

1550x1950x1550

1600x2000x1700

1700x2100x1750

Temperature Range of Testing zone

Type A:-40 ºC~+150ºC ( 200ºC is Optional)

Type B:-55ºC ~+150ºC ( 200ºC is Optional )

Type C:-65ºC ~+150ºC ( 200ºC is Optional)

High temperature Range of Testing zone: +60ºC~+150ºC ( 200ºC is Optional);
Low Temperature Range of Testing Zone: -10ºC~-40ºC / -55ºC / -65ºC

Control Accuracy / Distribution Uniformity

±0.5ºC/±2ºC

Internal and External Material

Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or see cold-rolled steel with paint coated.

Mechanics

P.I.D+S.S.R+ Micro-computer balanced temperature control system

Cooling System

Semi-hermetic double-stage compressor(water-cooled type) /Hermetic double-stage compressor (air-cooled type)
