| Model | THV-343(A~F) | THV-1000(A~F) | THV-3375(A~F) |
| Internal Dimension W×H×D(mm) | 700×700×700 | 1000×1000×1000 | 1500×1500×1500 |
| External Dimension W×H×D(mm) | 900×1950×2100 | 1300×2200×2400 | 1800×2400×3000 |
| Temperature Range | Low temperature: (A:25ºC; B:0ºC; C:-20ºC ; D: -40ºC; E: -60ºC; F: -70ºC) High temperature:100ºC(150ºC) | ||
| Humidity Range | 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H. is a special optional condition, need Dehumidifier) | ||
| Analytic Accuracy / Distribution uniformity of temperature and humidity | 0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H. | ||
| Control Accuracy of temperature and humidity | ±0.5ºC; ±2.5% R.H. | ||
| Temperature Rising / Falling Speed Rate | Temperature rising approx. 0.1~3.0ºC/mi temperature falling approx. 0.1~1.5ºC/min; (faster temperature change rate is optional) | ||
| Internal and External Material | Material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or SEE cold-rolled steel with paint coated. | ||
| Insulation Material | Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials | ||
| Cooling System | Wind cooling or water cooling/single segment compressor(-40ºC, double segment compressor -70ºC) | ||
| Protection Devices | Fuse-free switch, overloading protection switch for compressor,high and low voltage coolant protection switch, over- humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection | ||
| Optional Accessories | Inner door with operation hole(Optional) , Recorder(optional), Water Purifier, Dehumidifier | ||
| Vibration Test Equipment | Choose proper vibration test bench according to customer's test condition , the technical parameters please take Electrodynamics Type Vibration Tester's parameters in this catalog for reference | ||
| Power | AC380V 3∮ 5 Lines, 50/60HZ | ||
