Thương hiệu: ASLI
Thông số kỹ thuật:
| Model | TS-49(A~C) | TS-80(A~C) | TS-150(A~C) | TS-252(A~C) | TS-450(A~C) | ||||
| Internal Dimension WxHxD ( mm) | 400x350x350 | 500x400x400 | 600x500x500 | 700x600x600 | 800x750x750 | ||||
| External Dimension WxHxD (mm) | 1400x1800x1400 | 1550x1950 x1550 | 1600x2000 x1700 | 1700x2100 x1750 | 1800x2200 x1900 | ||||
| Temperature Range of Testing zone | Type A:-40 ºC~+150ºC ( 200ºC is Optional) | Type B:-55ºC ~+150ºC ( 200ºC is Optional ) | Type C:-65ºC ~+150ºC ( 200ºC is Optional) | ||||||
| High temperature Range of Testing zone: +60ºC~+150ºC ( 200ºC is Optional); Low Temperature Range of Testing Zone: -10ºC~-40ºC / -55ºC / -65ºC | |||||||||
| Exposure Time of High / Low Temperature | Exposure Time of High Temperature: +60ºC ~ +150ºC (200ºC is Optional) 30Mins | ||||||||
| Exposure Time of Low Temperature : -10ºC~Type A:-40ºC / Type B -55ºC / Type C -65ºC 30Mins | |||||||||
| Temperature of Heat-Storing Slot / Heating Time | RT~200ºC/About 45mins | ||||||||
| Temperature of Cool-storing Slot / Cooling Time | RT~-75ºC/ About 100mins | ||||||||
| Temperature Recovery Time / Conversion Time | ≤5min/≤5sec | ||||||||
| Control Accuracy / Distribution Uniformity | ±0.5ºC/±2ºC | ||||||||
| Internal and External Material | Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or see cold-rolled steel with paint coated. | ||||||||
| Insulation Material | High temperature resistant , high density , formate chlorine , ethyl acetum foam insulation materials | ||||||||
| Mechanics | P.I.D+S.S.R+ Micro-computer balanced temperature control system | ||||||||
| Cooling System | Semi-hermetic double-stage compressor(water-cooled type) /Hermetic double-stage compressor (air-cooled type) | ||||||||
| Security Protection Devices | Non-fuse breaker, high and low pressure protective switch of the compressor , refrigerator high-pressure protective switch , failure warning system, electronic alarm | ||||||||
| Accessories | viewing window(special order) | ||||||||
| Compressor | French 'Tecumseh' Brand, Germany Bizer Brand | ||||||||
| Power | AC220V 1∮ 3 lines ,50/60HZ, AC380V 3∮ 5 lines ,50/60HZ | ||||||||
| Weight (Approx) | 450 | 600 | 750 | 950 | 1200 | ||||
